GoodWe Hybrid inverter, Li-Ion battery, 3-phase, 10kW, 16A MPP

The GoodWe ET G2 Series is a next-generation high-voltage, three-phase hybrid inverter solution designed to meet the evolving demands of residential energy systems. With support for up to three MPPTs and output capacities ranging from 6kW to 15kW, the ET G2 Series enables flexible energy management, scalability, and superior energy...
Vendor: Goodwe
SKU: GW10K-ET-20
Availability: Out Of Stock
Product type: Solar PV Inverters
Please hurry! Only 0 left in stock
Description
Description
x

The GoodWe ET G2 Series is a next-generation high-voltage, three-phase hybrid inverter solution designed to meet the evolving demands of residential energy systems. With support for up to three MPPTs and output capacities ranging from 6kW to 15kW, the ET G2 Series enables flexible energy management, scalability, and superior energy yields. Its elegant and compact design ensures a seamless integration into modern homes, while intelligent control features and advanced protection mechanisms make it an ideal choice for reliable and efficient hybrid solar applications.

Key Features

  • High Efficiency: Up to 98.2% max. efficiency with 99.5% MPPT efficiency
  • Flexible Scalability: Supports parallel connection of up to 6 units
  • Smart Load Management: Integrated dry contact, UPS-level backup (<10ms), peak shaving
  • Robust Protection: Type II SPD on DC & AC sides, IP66 ingress protection, integrated AFCI
  • Flexible Installation: Plug & play design, natural convection cooling, wall-mounted
  • Wide Battery Compatibility: Works with high-voltage Li-ion batteries (150–720V)
Specifications
Specifications
x
Power Range
6kW – 15kW nominal AC output
MPPTs
Up to 3 Maximum Power Point Trackers with 16A input current per MPPT
Battery Voltage Range
150 – 720V (Nominal: 500V), 1 input, max. 40A charge/discharge
DC Oversizing
Up to 200% DC input oversizing supported
Max. Efficiency
Up to 98.2%, 97.5% European efficiency, 97.5% battery-to-AC efficiency
Backup Power
Nominal 6–15kVA with surge capacity up to 18000VA (60s)
Grid Interaction
400/380V 3-phase; 45–65Hz; max. current up to 21.7A
Protection Features
Type II SPD, AFCI, anti-islanding, RCMU, reverse polarity, over/short circuit
Ingress Protection
IP66, outdoor rated; -35°C to +60°C operating range
Communication & Monitoring
RS485, CAN, WiFi, LAN, Bluetooth; LED + app interface
Documents
Documents
x

Datasheet
