Description
xThe Esdec FlatFix Fusion Anchor Bar is a premium stainless-steel stabilisation component designed for use with the FlatFix Fusion modular mounting system. It provides a robust anchoring solution for rooftop PV installations, especially in wind-sensitive or ballast-reduced designs. Adjustable between 1600–1780 mm, the anchor bar ensures secure attachment to the roof substructure, improving system rigidity and safety.
Key Features
- Adjustable length for flexible system integration (1600–1780 mm)
- Corrosion-resistant stainless-steel construction
- Engineered for ballast-free or low-ballast mounting
- Compatible with Esdec FlatFix Fusion system
Specifications
xMaterial
Stainless steel (AISI 304 or equivalent)
Adjustable Length
1600 mm to 1780 mm
Application
Anchor support for rooftop PV systems
System Compatibility
Esdec FlatFix Fusion
Installation Type
Permanent, fixed to roof substructure
Corrosion Resistance
High, suitable for outdoor environments
Surface Finish
Brushed or passivated
Fastening Method
Bolted connection to roof anchors
Load-Bearing Function
Wind uplift and structural reinforcement
Standards Compliance
EN ISO 9227 / NEN-EN 1991-1-4
