Description
xThe Allbrox 8 String Combiner Box is engineered for photovoltaic (PV) installations requiring efficient and safe string-level power management. Designed with fuse protection and an integrated 1000VDC surge protection device (SPD), this unit offers enhanced protection against overcurrents and voltage surges, making it ideal for high-voltage PV systems. The robust enclosure ensures long-term reliability in outdoor environments.
Key Features
- Supports up to 8 PV input strings
- Integrated 1000VDC Type II SPD for surge protection
- Individual string fuse protection
- Weather-resistant IP65-rated enclosure
Specifications
xMaximum Input Strings
8
Maximum Voltage Rating
1000VDC
Surge Protection
Type II SPD, 1000VDC
Fuse Type
10×38mm cylindrical fuse holders
Rated Current per String
Up to 15A
Enclosure Protection Rating
IP65
Cable Entry
Gland type or MC4-compatible
Busbar Rating
≥160A total output
Operating Temperature Range
-25°C to +60°C
